8.9. Connexion



8.9.1. Logging in

At this stage it is possible to log in and check the result.

To do this:



8.9.1.1. Select Menu > Login;

8.9.1.2. In the appeared window, click Yes;

8.9.1.3. In the User field enter jsmith;

8.9.1.4. In the Password field, enter jsmithpw;

8.9.1.5. Select the Save Password item;

8.9.1.6. Click Login.



On the left, you will see a desktop and a list of available objects.







8.9.2. Result

After creating the above objects, you can check their operation:

action 1210 Files opens the corresponding table with attached files;

action 1213 Upload uploads file to the database from a local disk;

action 1211 Open opens file;

action 1212 Download downloads file from the database to the local disk;

action 1214 Delete closes file from viewing, leaving the file itself in the database.





8.9.3. Next

Step 9. Incoming Mail
